Non-contact measurement with ChromaLine sensor

MPLS-DM SERIES

Based on STIL's chromatic confocal technology, ChromaLine sensor family represents the next step in industrial integration.

Thanks to its accuracy, its robustness and a life span of several years without any maintenance, MPLS sensors are adapted to the requirements of on-line control.

Chromaline sensor MPLS180-DM series
DESCRIPTION

With 180 measuring points aligned along a line ranging from 1 to 12 millimeters, the new MPLS-DM version enables high-quality inspection with new capabilities, and working frequencies up to 2kHz in standard mode, and even 6kHz with a reduced sensor measuring range.

BENEFITS
  • Versatile: measures any material capable of reflecting white light (e.g. metal, glass, plastic, paint films, liquids)
  • Industrial thanks to its optical head made exclusively of passive components
  • Up to 360,000 measured points/second allows to work in all industries in standard 2Klines/second
  • More than 1 million points/second are acquired on dedicated applications at 6Klines / second
  • Distance and thickness measurements
  • High measurement accuracy
  • Availability of SDK and protocol commands for easy integration into any system
  • Synchronized measurement with encoder for dynamic acquisitions
  • Ethernet communication
TECH SPECS

Model

Unit

NANOVIEW

MICROVIEW

WIREVIEW

DEEPVIEW

SUPERVIEW

Order Code



OPSTM705001

OPSTM706001

OPSTM710001

OPSTM707002

OPSTM711001

Line Length

mm

1,34

1,8

1,51

4,2

12,85

Measuring Range 2kHz

µm

120

500

900

2600

2000

Working Distance

mm

7,4

10,1

7,8

19,5

11,3

Numerical Aperture



0,75

0,5

0,75

0,37

0,33

Max. Sample Slope

°

43

30

46

20

17

Pitch (dist. between 2 points)

µm

7,5

10,1

8,5

23,5

71,8

Spot Size

µm

2,9

3,8

3,2

8,8

27,2

Static Noise

nm

25

100

150

300

300

Axial Resolution

µm

0,15

0,6

0,9

1,8

1,8

Max. Linearity Error

nm

40

80

100

120

120

Homogeneity

nm

30

125

200

400

400

Min. Measurable Thickness

µm

18

50

110

250

300

Optical Part : Length

mm

434,4

425,6

480,7

428,3

397,8

Optical Part: Diameter

mm

50

50

70

60

60

Optical Part : Weight

g

1700

1600

2200

2800

2550

MR 4kHz

µm

55*

235*

450*

1150*

900*

MR 6kHz

µm

30*

120*

240*

650*

500*



Controller

MPLS-DM

Technology

Chromatic Confocal

Source

White LED

Number of Points

180

Measuring Frequency

200 Hz - 2000 Hz
(up to 6000z decreasing MR)

Distance Measurement

Highest/First/Second/Third/Fourth/Last Peak

Thickness Measurement

2 of 5 peaks

Digital Output

GigaEthernet

Synchronization

Trigger in&out

Other Input/Output

Encoder Input (1)

Fiber Bundle Length

5m

Temperature in Use

5°C - 50°C

Storage Temperature

-30°C - 70°C

Relative Humidity

5% - 80% HR without condensation

Protection type

IP 20

Compliance

EN 61010-1; EN 61326-1

Power Supply

100-240V AC

Maximum/Usual Consumption

120W/70W

Dimensions

448,9mm x 184mm x 497mm

Weight

15,2kg

APPLICATIONS

The chromatic confocal technology of ChromaLine sensor is suitable for a variety of applications in many fields:

  • Automotive glass
  • Glass containers and packaging industry
  • Electrical vehicle industry (batteries)
  • Applications for measuring roll-to-roll, transparent and non-transparent films (e.g. EV battery covers, flexible electronics)
  • Electronics Industry (PCB)
  • Semiconductor industry (silicon wafer)
  • CCC industry
  • Medical
  • Micromechanics
  • Aviation/Aerospace
  • Watchmaking
  • Robotics
VERSIONS

ChromaLine sensors are available as standard in five versions: MPLS180DM NanoView, MicroView, WireView, DeepView and SuperView.

Download

BROCHURES AND MANUALS

Data Sheet
English MPLS-DM SERIES: (847.59kB)
