Gauge for Grinding Machine

P3ME

For dimensional control on grinding machines, P3ME electronic unit represents a precise, reliable, economic and compact solution. The P3ME when connected to Marposs measuring heads can position the part and control the part dimensions during the whole grinding process.

DESCRIPTION

The P3ME when connected to Marposs measuring heads can position the part and control the part dimensions in various types of grinding machines. The gauge measure the part stock removed during the grinding process. The operator can view the analogue meter and digital display for part status in real time and the set of LEDs show the signals to the machine control system to manage the wheel feed.

Our range of systems are able to withstand the harsh process while being in direct contact with abrasive grit, metallic particles, cutting oils and aggressive coolants.

BENEFITS
  • Constant productivity is assured and maintained
  • Reat time part quality check during the grinding
  • Grinding wheel wear compensation
  • Cycle time optimization
  • Part production within tolerance
  • Operator influence minimised
  • Integration with machine logic
TECH SPECS

For all technical characteristics, please refer to the brochure in the DOWNLOAD section

VERSIONS

P3ME is supplied as stand alone unit to be installed on the top of the machine or in a rack version shape to be integrated inside a machine’s panel. The gauge features can be adapted according to the application and part type.

External grinder

  • Smooth part control
  • Part with interrupted surfaces control thanks to additional elaboration board
  • Part position check
  • I/O inputs for measure compensation
  • Head’s finger retraction management (Marposs’s heads contacts are retracted to avoid any interference with the part during the head movement)

Internal grinder

  • Smooth part control (Marposs head is always touching the part)
  • Control of workpieces with interrupted surfaces or head/wheel reciprocating movement, thanks to additional elaboration board
  • I/O inputs for measure compensation
  • Head’s finger retraction management (Marposs’s heads contacts are retracted to avoid any interference with the part during the head movement)

Surface grinder

  • Smooth part control (Marposs head is always touching the part)
  • Control of workpieces with interrupted surfaces or Marposs heads moving up and down the part, thanks to additional elaboration board
  • I/O inputs for measure compensation
  • Head’s finger retraction management (Marposs’s heads contacts are retracted to avoid any interference with the part during the head movement)
