Welding electrodes flux coating checking is now easy, quick and accurate.

MECLAB X40 WE

MECLAB.X40 WE is a high-performance tabletop laser micrometer for the off-line measuring of the diameter of the flux coating and it’s eccentricity relative to the core wire.



MECLABX40 WE

How does it work?
The wet electrode is placed in the “V” Block and it is manually rotated with a little pressure.
The Flux is removed at the point of V-Block and the electrode will rotate with core wire.
The laser system measures the diameter of the flux coating and it’s eccentricity relative to the core wire.
The measurements are showed in the display for an immediate dimesion check.
In this way it is possible to control the quality of the coating and regulate the production.

利点

​Repeatable and objective results not affected by operator’s skill.

Highly flexible:
different diameters can be measured without system re-mastering.

Rugged construction suitable to be used in workshop environment.

Easy to use
The software has been designed to be extremely user friendly and very flexible.

Quick tolerance check
Measured dimensions can be compared with a pre-set nominal value and a tolerance range: colours will immediatelydisplay the tolerance status of the part.

Part library for easy programming
Up to 5000 control sets (tolerance limits, measuring mode, etc.) can be stored in a “part library”.

No measuring drift due to changing room temperature!
The NO-VAR (NO-VARiation) technology allows to get simply perfect measurements even in non-thermally controlled environments, programming the thermal expansion coefficient of different materials.

ダウンロード

カタログおよびマニュアル

パンフレット
英語 MECLAB X40 WE: (1.01MB)
